Item: P/N Qty: Description:
MechFiber340 MechFiber360
14 FP160-006-0139 same as 340 2 Load bumper brace plate
15 FP160-045-0118 same as 340 1 BaleBlend kicker assembly – complete kit
16 FP140-045-0019 same as 340 As Req’d Spacer Plate, 3mm, for BaleBlend Bracket
17 700247 same as 340 10/11 M12 x 30mm setscrew
18 700730 same as 340 10/11 M12 Flat washer
19 700266 same as 340 10/11 M12 Locknut
20 700732 same as 340 23 M16 Flat washer
21 700283 same as 340 15 M16 locknut
22 700739 same as 340 8 M16 spring washer
23 700275 same as 340 8 M16 x 50mm bolt
24 FP140-045-0111 same as 340 9/11 M24 x 150mm Bolt with Grease Nipple
(701127) Fitted
25 700729 same as 340 13 M10 Flat washer
26 700241 same as 340 13 M10 Locknut
27 700281 same as 340 4 M16 x 90mm bolt
28 FP200-045-0162 same as 340 3 BaleBlend Tine Assembly (Extra Drop) M24
Bolt
29 FP160-045-0094 same as 340 2 BaleBlend Kicker arm mounting bracket
(weld on)
30 FP280-045-017 same as 340 2 BaleBlend Creel guide arm
31 FP160-045-0088 same as 340 1 Creel End Cover Plate
32 FP160-045-0003 same as 340 1 BaleBlend End Creel Assembly (Rear)
33 700733 same as 340 2 M20 Washer
34 FP160-045-0002 same as 340 1 BaleBlend End Creel Assembly (Front)
35 704040 same as 340 2 End Creel Ram Assembly
36 701112 same as 340 2 R Clip
37 700746 same as 340 2 M25 Flat washer
38 FP280-045-010 same as 340 2 BaleBlend Nylon Guide Wheel
39 700269 same as 340 2 M16 x 110mm Bolt
40 700228 same as 340 13 M10 x 35mm Bolt
41 FP160-045-0075 FP200-045-0103 1 Kicker Assembly, Rubber Mount Assembly
42 700247 same as 340 6 M12 x 30mm Bolt
43 700266 same as 340 6 M12 Locknut
44 700730 same as 340 6 M12 Washer
45 700732 same as 340 2 M16 Washer
46 700283 same as 340 2 M16 Locknut
47 700732 same as 340 9 M16 Washer
48 700283 same as 340 9 M16 Locknut
50 FP140-045-0003 FP200-045-0003 1 Rubber Apron
51 FP160-050-0003 FP200-050-0008 1 Load Bumper Rubber
Table 27: Series III BaleBlend
