0180036-J0 Rev E Page 18
Hardware Specifications
CPU: Texas Instruments Piccolo
LED’s: Communication established (Green), Power (Blue)
Mounting: 4 holes on standard CXCHP pitch, optional DIN rail mounting kit
Weight: 1 kg (2 lb.)
Power Requirements: 90-300VDC 50W
125VDC 0.4A
220VDC 0.2A
Analog Inputs:
2 voltage +/-300VDC
1 current (shunt range 25mV to 200mV)
2 temperature (using Alpha sensor)
2 DCCT (hall effect current sensor with bias voltage) +-10VDC signal
+-15VDC Bias for sensor
Ground Fault Detect
Alarms:
1 user configurable on V2 input (current detect up to 15mA and resistance
measurement option)
Digital Inputs: 4 contact closure detect only, MAX VOLTAGE 5VDC
Relay Outputs: 6 Form C, 220VDC 50W max
Communication Ports: Isolated CAN
Low Voltage (30V) protected power output to run CXC-HP controller and
other low voltage ADIO modules (Maximum 0.7A/25W output)
Recommended Connection Wire Sizes
Wire Size: #18 to #24 AWG 600V
Table 3: Specifications: HV-ADIO (Continued) (Sheet 2 of 2)
