Antenna Receptacle
@ Power Antenna Lead (Blue)
Connect this lead to the +B terminal of your power antenna,
if applicable.
• This lead should be used
onlyfor
controlling the vehicle's power
alltenna. Do not use this lead
to
tum
on
till
amplifier, or a signal
processor, etc.
@ Remote Turn-On Lead (BlueJWhite)
Connect this lead to the remote turn-on lead of your
amplifier or signal processor. When an IMPRINT audio
processor PXA-H100 (sold separately)
is
connected, use
the Remote Turn-on lead of PXA-H100 to connect to your
amplifier or signal processor. For details, refer to the
Owner's Manual of PXA-H100.
@ Audio Interrupt
In
Lead (Pink/Black)
Connect this lead to the Audio interface output of a cellular
phone which provides ground shorting when a call
is
received.
(~)
Illumination Lead (Orange)
This lead may be connected to the vehicle's instrument
cluster illumination lead. This will allow the backlighting of
the CDA-1 05
to
dim whenever the vehicle's lights are turned
on.
@ Switched Power Lead (Ignition) (Red)
Connect this lead to an open terminal on the vehicle's fuse
box or another unused power source which provides (+)12V
only when the ignition is turned on or
in
the accessory
position.
(j)
Battery Lead (Yellow)
Connect this lead to the positive (+) post of the vehicle's
battery
(8)
Ground Lead (Black)
Connect this lead to a good chassis ground on the vehicle.
Make sure the connection
is
made
to
bare metal and
is
securely fastened using the sheet metal screw provided.
® Power Supply Connector
@ Right Front (+) Speaker Output Lead (Gray)
(f)}
Right Front H Speaker Output Lead (GraylBlack)
(it
Right Rear H Speaker Output Lead (VioletIBlack)
@)
Right Rear (+) Speaker Output Lead (Violet)
(!..~
Left Rear (+) Speaker Output Lead (Green)
@ Left Rear
(-)
Speaker Output Lead (Green/Black)
(i~
Left Front
(-)
Speaker Output Lead (White/Black)
(jIi
Left Front (+) Speaker Output Lead (White)
@ Fuse Holder
(1
OA)
;r~)
Ai-NET Connector
Connect this to the output or input connector of another
device (CD Changer, IMPRINT audio processor, Equalizer,
HD Radio TUNER MODULE, etc.) equipped with
Ai-NET.
• Interface adapterfor iPod (KCA-420i) is not recommended for use
with this product.
•
You
can input TV/video sound by connecting an optional Ai-NET/
RCA Interface cable (KCA
-121
B)
to
this component.
• Be sure to set "Setting the Connected Head Unit (MODEL SETUP)"
to
"CD
CHG", when the DHA-S690 is connected.
@ Steering Remote Control Interface Connector
To
steering Remote control interface box.
rij)
Rear Outputllnput RCA Connectors
It can be used as Rear Output or Input RCA Connectors.
RED
is right and WHITE is left.
(.@
Front Outputllnput RCA Connectors
It can be used as Front Output or Input RCA Connectors.
RED
is
right and WHITE
is
left
@ Subwoofer RCA Connectors
RED
is
right and WHITE is
left
~~
Ai-NET Cable (Included with CD Changer)
~}
RCA Extension Cable (sold separately)
@ Bluetooth interface connector
Connect this to
an
optional Bluetooth INTERFACE
(KCE-400BT).
To
use a hands-free mobile phone,
an
optional Bluetooth INTERFACE (KCE-400BT) connection is
required. For details
on
connection, refer to the Owner's
Manual of the Bluetooth INTERFACE (KCE-400BT).
You
can
also connect this to an external device (such as a portable
player)
by
using conversion cable (KCE-237B) for building
up the AUX
IN
(sold separately).
* Refer to "Setting the AUX+ SETUP Mode" (page
18).
AUX+
ON
:
When
the
external device
is
connected.
AUX+
OFF:
When
set
to
OFF,
AUX+
source cannot be
selected.
:'if)
KCE·400BT Connection Cable (Included with
KCE-400BT)
@ System Switch
When connecting a processor or divider using
Ai-NET,
place the two switches
in
the
EXT
AP
position. When
no
device
is
connected, leave the switch
in
the NORM position.
• Do not make the two switches
to
different settings.
• Be sure
to
turn the power
off
to the unit before changing the switch
position.
(i~
USB Connector
Connect this
to
an
USB memory or
to
an iPhone/iPod.
To
use an iPhone/iPod, Interface cable for iPod (KCU-440i,
sold separately) connection is required.
• Route the USB cable away from other cables.
To
prevent external noise from entering the audio system.
• Locate the unit and route the leads at least
10
em away from the car harness.
• Keep the battery power leads
as
far away from other leads
as
possible.
• Connect the ground lead securely to a bare metal spot (remove any paint, dirt or grease if necessary)
of
the car chassis.
• If you add
an
optional noise suppressor, connect it
as
far away from the unit as possible. Your Alpine dealer carries various noise
suppressors, contact them for further information.
• Your Alpine dealer knows best about noise prevention measures so consult your dealer for further information.
