8
English
Detachable Front
Panel
Detaching the Front
Panel
Note: To protect the front panel, place it in the
supplied carrying case.
1
Press the PWR button to turn off the power.
Press the release button until the front panel
pops out.
Grasp the left side of the front panel and pull it
out.
2
3
English
1
2
PWR
