Maintenance
Intervention on the operating device
L51--302EN/01
2/10
10--1999
E ALSTOM
Positions of optical signalization
“A” position
Circuit--
breaker
Open
Closing spring
Loaded
“B” position
Circuit--
breaker
Closed
Closing spring
Released
“C” position
Circuit--
breaker
Closed
Closing spring
Loaded
“D” position
Circuit--
breaker
Open
Closing spring
Released
