Alstom GL314 - Description and Operation; General Description of the Circuit-Breaker

Description and operation
General descrip tio n of the circuit--breaker
L12--016EN/01
1/6
06--2003
E ALSTOM
Circuit--b reaker GL314 with spring o p erating mechanism FK3--1
Description
The circuit--breaker is made up of three poles, each activated by a spring op-
erating mechanism.
Diagram
C
A
B
D
Parts table
The table below gives the main parts of the circuit--breaker :
Mark Component Page
A Pole of the circuit--breaker 2
B Support--frame 3
C Operating device 4
D Marshalling cubicle 5
