Instruction manual
OPERATION
822/834
2.4 TOWING, RECOVERY AND TRANSPORT OF THE MACHINE, 822/834
WARNING! Vehicle recovery may only be carried out at low speed and with great caution. When towing, do not exceed aspeed
of3 km/h and adistance farther than 200 m. Tow to the nearest rm ground for repair or transport on atrailer, etc.
Recovery
When recovering the machine:
Front – use the towing points in the chassis (see gure 1).
Rear – use the designated attachment points (see gure 2.)
Always set the crane in the parked position and remove any load.
Always maintain asafe distance and be aware of the risk of overturning.
If the engine is running, put the gear shift lever in neutral.
WARNING! Steering is unavailable when the engine is switched o.
Transport
When transporting the machine on atrailer or other means of transportation, secure it safely. During transport, the machine must be
secured so that it is able to counteract aforward force that is equal to the full total weight as well as to the rear and sides that is equal to
at least half the total weight. We recommend using tensioning straps since standard ropes are unsuitable because they can stretch when
subjected to heavy loads. Check the condition of the tensioning straps and replace them if damaged. Apply the parking brake and switch
o the main power switch. During machine transport, the crane arm should always be in the parked position and locked. Please make
sure you have the requisite driving license qualications that apply for your transport vehicle. Normally, the machine should rest on all
eight wheels.
1 2
