Instruction manual
TECHNICAL SPECIFICATIONS
4.2 DIMENSIONS AND WEIGHT
Models 850 and 850 H
Kerb weight 850/2,650 kg | 850 H/4,000 kg
Width 850/1,580 mm | 850 H 1,650 mm
Ground clearance 376 mm
Load capacity 3,000 kg
Obstruction clearance 510 mm
300/340
1640/1659
376/401
Ø 620/670
2558/2583
