EAV64301 01/2015 23
Temperature Conditions
Climatic Environmental Conditions for Transportation and Storage
The environment during transportation and storage must be dry and free from dust.
Climatic Environmental Conditions for Operation
The maximum permissible ambient temperature during operation depends on the mounting distances
between the devices and on the required power. Observe the pertinent instructions in the chapter Drive
Mounting (see page 53).
(1) Refer to Derating Curves section (see page 46).
Altitude Conditions
Operating Altitude
Operating possibilities according to the altitude
Storage Temperature °C -40...70
°F -40...158
Transportation Temperature °C -40...70
°F -40...158
Relative humidity % 5...95
Frame sizes 1...6
ATV630••••• products
Temperature without derating °C -15...50
°F 5...122
Temperature with derating of output power (1) °C Up to 60
°F Up to 140
Frame sizes A...C
ATV650••••• products
Temperature without derating °C -15...40
°F 5...104
Temperature with derating of output power (1) °C Up to 50
°F Up to 122
All products Relative humidity without condensing % 5...95
Altitude Supply
voltage
Supply Electrical Network Derating
TT/TN IT Corner-
Grounded
Up to 1000 m (3300 ft) 200..240 V o
380..480 V o
1000...2000 m (3300...6600 ft) 200..240 V
380..480 V
2000...3800 m (6600...12400 ft) 200..240 V
380..480 V –
3800...4800 m (12400...15700 ft) 200..240 V
380..480 V – –
Legend: : Derate the nominal current of the drive by 1% for each additional 100 m.
o: Without derating
–: Not applicable
