Checking Installation
Chapter 5
Checking Installation
Check List Before Switching On
Mechanical Installation
Verify the mechanical installation of the entire drive system:
Electrical installation
Verify the electrical connections and the cabling:
Covers And Seals
Verify that all covers and seals of the control cabinet are properly installed to meet the required degree of
protection.
Step Action
1 Does the installation meet the specified distance requirements?
2 Did you tighten all fastening screws with the specified tightening torque?
Step Action
1 Did you connect all protective ground conductors?
2 Do all fuses and circuit breaker have the correct rating; are the fuses of the specified type? (refer to
the catalog and the Getting Started Annex available with the product).
3 Did you connect or insulate all wires at the cable ends?
4 Did you properly connect and install all cables and connectors?
5 Do all plug-in terminals colors and markings correspond to the colors and marking of the control
block?
6 Did you properly connect the signal wires?
7 Are the required shield connections EMC-compliant?
8 Did you take all measures for EMC compliance?
