EAV64301 01/2015
Maintenanc e
Chapter 6
Maintenance
Scheduled servicing
Servicing
NOTE: The fan operation depends of the drive thermal state. The drive may be running and the fan not.
Diagnostic And Troubleshooting
Refer to the Programming Manual available on www.schneider-electric.com.
Spares and repairs
Serviceable product. Please refer to your Customer Care Center.
DANGER
HAZARD OF ELECTRIC SHOCK, EXPLOSION OR ARC FLASH
Read and understand the instructions in Safety Information chapter before performing any procedure
in this chapter.
Failure to follow these instructions will result in death or serious injury.
WARNING
HOT SURFACES
z Ensure that any contact with hot surfaces is avoided.
z Do not allow flammable or heat-sensitive parts in the immediate vicinity of hot surfaces.
z Verify that the heat dissipation is sufficient by performing a test run under maximum load conditions.
Failure to follow these instructions can result in death, serious injury, or equipment damage.
NOTICE
RISK OF DAMAGE TO THE DRIVE
Perform the following activities.
Failure to follow these instructions can result in equipment damage.
Environment Part concerned Action Periodicity
Knock on the
product
Housing - control block (led -
display)
Verify the drive visual aspect At least each year
Corrosion Terminals - connector - screws -
EMC plate
Inspect and clean if required
Dust Terminals - fans - blowholes -
enclosures air inlets and outlets -
cabinets air filters
Inspect and clean if required
Temperature Around the product Verify and correct if required
Cooling Fan Verify the fan operation At least each year
Replace the fan, see catalog and
the instructions sheets on
www.schneider-electric.com.
After 3 to 5 years,
depending on the operating
conditions
Vibration Terminal connections Verify tightening torques At least each year
