Altivar Process ATV650 - Drive Ratings in Normal Duty

40 EAV64301 01/2015
Drive Ratings In Normal Duty
Normal Duty
Normal duty values are given for applications requiring a slight overload (up to 110 %).
IP21 / UL Type 1 Products 3-Phase Power Part Supply 200…240 Vac 50/60 Hz
Catalog Number and
Frame Size (S•)
Nominal Power
(1)
Power Part Supply Drive (output)
Max. Input
Current
Apparent
Power
Max.
Inrush
Current
(2)
Nominal
Current (1)
Max.
Transient
current (1)
(3)
At
200 Vac
At
240 Vac
kW HP A A kVA A A A
ATV630U07M3 S1 0.75 1 3 2.6 1.1 4.3 4.6 5.1
ATV630U15M3 S1 1.5 2 5.9 5 2.1 4.3 8 8.8
ATV630U22M3 S1 2.2 3 8.4 7.2 3.0 4.3 11.2 12.3
ATV630U30M3 S1 3 - 11.5 9.9 4.1 17.5 13.7 15.1
ATV630U40M3 S1 4 5 15.1 12.9 5.4 17.6 18.7 20.6
ATV630U55M3 S2 5.5
7
1/2
20.2 17.1 7.1 30.9 25.4 27.9
ATV630U75M3 S3 7.5 10 27.1 22.8 9.5 30.9 32.7 36.
ATV630D11M3 S3 11 15 39.3 32.9 13.7 39.3 46.8 51.5
ATV630D15M3 S4 15 20 52.6 45.5 18.9 64.6 63.4 69.7
ATV630D18M3 S4 18.5 25 66.7 54.5 22.7 71.3 78.4 86.2
ATV630D22M3 S4 22 30 76 64.3 26.7 70.9 92.6 101.9
ATV630D30M3 S5 30 40 104.7 88.6 36.8 133.3 123 135.3
ATV630D37M3 S5 37 50 128 107.8 44.8 133.3 149 163.9
ATV630D45M3 S5 45 60 155.1 130.4 54.2 175 176 193.6
ATV630D55M3 S6 55 75 189 161 61.1 168.2 211 232.1
ATV630D75M3 S6 75 100 256 215 83.7 168.2 282 310.2
(1) The switching frequency is adjustable:
z From 1...16 kHz for drive frame sizes 1 to 4, rated value: 4 kHz
z From 1...8 kHz for drive frame sizes 5 and 6, rated value: 2.5 kHz
For operation at switching frequencies higher than the rated value. Derating must be applied to the drive (output)
current (see page 46). In this case, switching frequency can be reduced if an excessive temperature rise occurs.
(2) Peak current when power is switched On, for the maximum supply mains voltage.
(3) The drive is designed to run up to 60 s at 110% of nominal current.
