34 EAV64301 01/2015
Frame Size A With Load Switch
ATV650U07N4E, U15N4E, U22N4E, U30N4E, U40N4E, U55N4E: a = 300 mm (11.8 in.)
ATV650U75N4E, D11N4E, D15N4E, D18N4E, D22N4E: a = 330 mm (13 in.)
Weights
Catalog Number Weight in kg (lb)
ATV650U07N4ï...ATV650U22N4ï 10.5 (23.1)
ATV650U30N4ï, ATV650U40N4ï 10.6 (23.4)
ATV650U55N4ï 10.7 (23.6)
ATV650U75N4ï, ATV650D11N4ï 13.7 (30.2)
ATV650D15N4ï 19.6 (43.2)
ATV650D18N4ï, ATV650D22N4ï 20.6 (45.4)
