Altivar Process ATV650 - Page 42

42 EAV64301 01/2015
IP55 Products 3-Phase Power Part Supply 380…480 Vac 50/60 Hz
Catalog Number and
Frame Size (S•)
Nominal Power
(1)
Power Part Supply Drive (output)
Max. Input
Current
Apparent
Power
Max.
Inrush
Current
(2)
Nominal
Current
(1)
Max.
Transient
current (1)
(3)
At
380 Vac
At
480 Vac
kW HP A A kVA A A A
ATV650U07N4 SA 0.75 1 1.5 1.3 1.1 8 2.2 2.4
ATV650U15N4 SA 1.5 2 3 2.6 2.2 8.3 4 4.4
ATV650U22N4 SA 2.2 3 4.3 3.8 3.2 8.4 5.6 6.2
ATV650U30N4 SA 3 - 5.8 5.1 4.2 31.5 7.2 7.9
ATV650U40N4 SA 4 5 7.6 6.7 5.6 32.2 9.3 10.2
ATV650U55N4 SA 5.5
7
1/2
10.4 9.1 7.6 33.2 12.7 14
ATV650U75N4 SA 7.5 10 13.8 11.9 9.9 39.9 16.5 18.2
ATV650D11N4 SA 11 15 19.8 17 14.1 40.4 23.5 25.9
ATV650D15N4 SA 15 20 27 23.3 19.4 74.5 31.7 34.9
ATV650D18N4 SA 18.5 25 33.4 28.9 24 75.5 39.2 43.1
ATV650D22N4 SA 22 30 39.6 34.4 28.6 76 46.3 50.9
ATV650D30N4 SB 30 40 53.3 45.9 38.2 83 61.5 67.7
ATV650D37N4 SB 37 50 66.2 57.3 47.6 92 74.5 82
ATV650D45N4 SB 45 60 79.8 69.1 57.4 110 88 96.8
ATV650D55N4 SC 55 75 97.2 84.2 70 176 106 116.6
ATV650D75N4 SC 75 100 131.3 112.7 93.7 187 145 159.5
ATV650D90N4 SC 90 125 156.2 135.8 112.9 236 173 190.3
(1) The switching frequency is adjustable:
z From 1...16 kHz for drive frame sizes A and B, rated value: 4 kHz
z From 1...8 kHz for drive frame size C, rated value: 2.5 kHz
For operation at switching frequencies higher than the rated value. Derating must be applied to the drive (output)
current (see page 46). In this case, switching frequency can be reduced if an excessive temperature rise occurs.
(2) Peak current when power is switched On, for the maximum supply mains voltage.
(3) The drive is designed to run up to 60 s at 110% of nominal current.
