72 EAV64301 01/2015
Frame Size B
Frame Size C
ATV650 Supply Terminals (L1, L2, L3) Output Power Terminals (U, V, W)
Wire Cross Section Tightening
Torque
Wire Cross Section Tightening
Torque
Minimum Maximum (1) Rated Minimum Maximum (1) Rated
mm² (AWG) mm² (AWG) N·m (lb.in) mm² (AWG) mm² (AWG) N·m (lb.in)
D30N4 16 (6) 50 (1) 5 (44.3) 25 (4) 50 (1) 5 (44.3)
D30N4E 16 (N/A) 50 (N/A) 22.6 (200) 25 (N/A) 50 (N/A) 5 (44.3)
D37N4 25 (4) 50 (1) 5 (44.3) 25 (4) 50 (1) 5 (44.3)
D37N4E 25 (N/A) 50 (N/A) 22.6 (200) 25 (N/A) 50 (N/A) 5 (44.3)
D45N4 35 (3) 50 (1) 5 (44.3) 35 (3) 50 (1) 5 (44.3)
D45N4E 35 (N/A) 50 (N/A) 22.6 (200) 35 (N/A) 50 (N/A) 5 (44.3)
(1) maximum permissible cross section of the terminal
ATV650 Supply Terminals (L1, L2, L3) Output Terminals (U, V, W)
Wire Cross Section Tightening
Torque
Wire Cross Section Tightening
Torque
Minimum Maximum (1) Rated Minimum Maximum (1) Rated
mm² (AWG) mm² (AWG) N·m (lb.in) mm² (AWG) mm² (AWG) N·m (lb.in)
D55N4 50 (1) 120 (250MCM) 10 (88.5) 50 (1) 120 (250MCM) 10 (88.5)
D55N4E 70 (N/A) 95 (N/A) 22.6 (200) 50 (N/A) 120 (N/A) 18 (159.3)
D75N4 70 (2/0) 120 (250MCM) 18 (159.3) 70 (2/0) 120 (250MCM) 18 (159.3)
D75N4E 95 (N/A) 95 (N/A) 22.6 (200) 70 (N/A) 120 (N/A) 18 (159.3)
D90N4 (2) 95 (3/0) 120 (250MCM) 18 (159.3) 95 (3/0) 120 (250MCM) 18 (159.3)
D90N4E (2) 95 (N/A) 95 (N/A) 22.6 (200) 95 (N/A) 120 (N/A) 18 (159.3)
(1) maximum permissible cross section of the terminal
(2) This drive requires class 90°C cables to connect the supply part.
