DI1-DI6 Digital inputs I 6 programmable logic inputs 24 Vdc, comply with IEC/EN 61131-2 logic
type 1
z Positive logic (Source): State 0 if 5 Vdc or logic input not wired,
state 1 if 11 Vdc
z Negative logic (Sink):State 0 if 16 Vdc or logic input not wired,
state 1 if 10 Vdc
z Impedance 3.5 kΩ
z Maximum voltage: 30 Vdc
z Maximum sampling time: 2 ms ± 0.5 ms
Multiple assignment makes it possible to configure several functions on
one input (example: DI1 assigned to forward and preset speed 2, DI3
assigned to reverse and preset speed 3).
DI5-DI6 Pulse inputs I Programmable Pulse input
z Comply with level 1 PLC, IEC 65A-68 standard
z State 0 if < 0.6 Vdc, state 1 if > 2.5 Vdc
z Pulse counter 0...30 kHz
z Frequency range: 0…30 kHz
z Cyclic ratio: 50 % ± 10 %
z Maximum input voltage 30 Vdc, < 10 mA
z Maximum sampling time: 5 ms ± 1 ms
10V Output supply for
Analog input
O Internal supply for the analog inputs
z 10.5 Vdc
z Tolerance ± 5%
z Current: maximum 10 mA
z Short circuit protected
AI1-AI2-
AI3
Analog inputs I Software-configurable V/A : voltage or current analog input
z Voltage analog input 0...10 Vdc, impedance 30 kΩ,
z Current analog input X-Y mA by programming X and Y from
0...20 mA, with impedance 250 Ω
z Maximum sampling time: 5 ms ± 1 ms
z Resolution 12 bits
z Accuracy: ± 0.6% for a temperature variation of 60°C
z Linearity ± 0.15% of maximum value
COM Analog common I/O 0 V for Analog outputs
AI2-AI3 Sensor inputs I Software-configurable PT100/PT1000 or KTY84 or PTC or Water level
sensor
z PT100
z 1 or 3 thermal sensors mounted in series (configurable by
software)
z Sensor current: 5 mA
z Range –20/200°C
z Accuracy +/– 4°C for a temperature variation of 60°C
z PT1000
z 1 or 3 thermal sensors mounted in series (configurable by
software)
z Thermal sensor current: 1 mA
z Range –20/200°C
z Accuracy +/– 4°C for a temperature variation of 60°C
z KTY84
z 1 thermal sensor
z Thermal sensor current: 1 mA
z Range –20/200°C
z Accuracy +/– 4°C for a temperature variation of 60°C
z PTC
z 6 sensors maximum mounted in series
z Sensor current: 1 mA
z Nominal value: < 1.5 kΩ
z Overheat trigger threshold: 2.9 kΩ
z Overheat reset threshold: 1.575 kΩ
z Protected for low impedance < 1000 Ω
z Water Level Sensor
z Sensitivity: 0...1 MΩ, adjustable by software
z Water level sensor current: 0.3 mA...1 mA maximum
z Adjustable delay: 0...10 s
Terminal Description I/O
Type
Electrical characteristics
