INSTALLATION
Del uxe Control C ook & Ho l d ▪ Opera tor’s Manual ▪ MN- 4 6708 ▪ Re v 1 ▪ 11/20
32
Continued from previous page
Position the oven To position the oven, do the following.
Step Action
1. Make sure that:
▪ The location where the oven is being installed is rated to support the
weight of the oven;
▪ The oven is within five feet (1.5 m) of the appropriate electrical outlet;
▪ You follow the oven clearance guidelines.
2. Move the oven to the installation location and onto the final resting surface.
Apply the brakes of the front casters.
3. See topic How to Clean the Oven, and thoroughly clean the oven before
continuing.
Connecting power 4. For ovens without plugs and cords, do the following (See topic How to
Connect the Electrical Wiring).
1. Remove the top panel.
2. Remove the cord grip that came with the oven from the restraint connector
and insert it into the power connection hole.
3. Connect the power wires to the terminal block and circuit breakers. Secure
the cord with the cord grip.
Tighten the cord grip nut.
4. Re-install the top panel.
For ovens with plugs and cords, do the following.
Plug the oven into a properly grounded receptacle.
Continued on next page
2" (51mm)
2" (51mm)
3" (76mm)
2" (51mm)
CEE 7/7
TH-TS-009925
NEMA 5-20PNEMA 5-15P BS-1363 CH2-16P
