20
Pad Description
OVEN CANCEL Cancels any cooking or cleaning function except timer.
TIMER ON/OFF Use to time any kitchen function or cancel timer.
Does not control bake, broil, or
clean function.
CLOCK Use to set time of day.
STOP TIME Use to set delayed bake and self-clean.
COOK TIME Use to set timed baking.
CLEAN Use to select self-clean cycle.
BROIL Use to select broil.
BAKE Use to select bake.
Use to set temperature or time.
Oven Signals
Timer signal
When time elapses, timer beeps 3 times then approximately once every 6-8
seconds.
Preheat signal After setting oven to bake and selecting a temperature, oven preheats. When
oven reaches set temperature, 1-second signal sounds.
End-of-Cycle signal When a timed cooking cycle is complete, three long signals sound. End of cycle
signal continues to sound until CLEAR/OFF pad is pushed.
If minute timer end of cycle signal is sounding, push TIMER ON/OFF pad.
Other Features
12-hour automatic Cancel This safety feature prevents oven from continuing to operate if it has been left on
for over 12 hours. If a cooking function continues longer than 12 hours without
any options on oven control being touched, this feature turns oven off. Any time
an option is touched, 12-hour automatic cancel is reset.
Service Codes and Tones
Electronic range control is equipped with a self diagnostic system. Self diagnostic
system alerts you if there is a error or problem in the control. If electronic range
control sounds a series of short, rapid beeps for over 16 seconds and display
shows a F-code, record the F-code shown. Some F-codes can be cleared by
touching CANCEL or disconnecting power to the range. If the code continues to
reoccur call an authorized servicer. Disconnect electrical supply to range and
contact an authorized servicer.
or
Electronic Range Control
TIMER
ON/OFF
CLOCK
STOP
TIME
COOK
TIME
OVEN
CANCEL
CLEAN
BROIL
BAKE
88:88
350
°
O
N
CLEAN
BROIL
LOCK
DELAY
OVEN ON
CLEAN
STOP
TIMER
BAKE
HR
Figure 32
