Amana SRD25S3 User Manual

RS1300003 Rev. 0 88 December 1997
Kit Instructions
DS21S Kit - Non Dispenser Models
Install 1/4 inch (6 millimeter) freezer door top
retainer (Item #6) by placing trim at an angle on
top edge of panel. Align straight end of trim flush
with panel corner. Press trim onto panel. Install
freezer door side retainer (Item #17), freezer door
bottom retainer (Item #6) then freezer door side
retainer (Item #17) on panel. Notched end of trim
must overlap straight end of previously installed
trim. Confirm trim is secure. Remove nameplate
by placing putty knife covered with masking tape
under nameplate and pulling forward. Discard
nameplate.
DS21S Kit - Dispenser Models
Install 1/4 inch (6 millimeter) upper and lower
freezer door top retainers (Item #6) by placing trim
at an angle on top edge of panel. Align straight end
of trim flush with panel corner. Press trim onto
panel. Install upper and lower freezer door right
side retainers (Items #12 or #14, respectively),
upper and lower freezer door bottom retainers
(Item #6) then upper and lower freezer door left
side retainers (Items #12 or #14, respectively) on
panel. Notched end of trim must overlap straight
end of previously installed trim. Confirm trim is
secure.
All Models
Caution
To prevent property damage, place masking tape on
back of panel at each corner. Tape prevents panel
from damaging doors.
1. Place masking tape on back of panels at each
corner.
2. Slide decorator door panels into place until panels
are secure. On DS19 and DS21 kits, handle side of
panel trim slides under handle trim. On DS20 and
DS20 kits, handle side of panel slides under handle
insert.
3. Install side door trim by peeling off 1 1/2 inches
(38 millimeters) of backing. Place trim against top
corner of refrigerator cabinet over edge of top trim.
After checking placement, peel off backing and
press into place. Place side door trim over edge of
bottom trim.
