Amana VCA - Condensing Unit Specifications

15 Rev. 3
CONDENSING UNIT SPECIFICATIONS
IMPORTANT NOTE:
WHILE THIS DATA IS PRESENTED AS A GUIDE, IT IS IMPORTANT TO ELECTRICALLY CONNECT THE UNIT
AND PROPERLY SIZE WIRES AND FUSES/CIRCUIT BREAKERS IN ACCORDANCE WITH THE NATIONAL
ELECTRICAL CODE AND/OR LOCAL CODES.
Amana
Square Base Hei
g
ht
RCB18B2A
RCB24B2A
RCB30B2A
VCA18B2A
VCA24B2A
VCA30B2A
22 - 1/2" 23"
RCA36B2A
RCB42B2A
VCA36B2A
VCA42B2A
28 - 1/2" 25"
RCB48B2A
RCB60B2A
VCA48B2A
VCA60B2A
28 - 1/2" 33"
Models
Dimensions
Square Base Height
RCA18A2A
RCB18A2A
RCC18A2B
VCB18A2B
26" 25-1/2"
RCA24A2B
RCB24A2B
RCC24A2B
RCE24A2A
VCB24A2B
26" 25-1/2"
RCA30A2A
RCB30A2A
RCB30A2B
RCB30A2C
RCC30A2B
RCE30A2A
VCB30A2B
29-1/2" 25-1/2"
RCA36A2A
RCB36A2B
RCB36A3B
RCB36A4B
RCC36A2B
RCC36A3B
RCE36A2A
VCB36A2B
29-1/2" 29-1/2"
RCA42A2A
RCB42A2A
RCC42A2B
RCE42A2A
VCB42A2B
29-1/2" 33-1/2"
RCA48A2A
RCB48A2B
RCB48A3B
RCB48A4B
RCC48A2B
RCC48A3B
RCE48A2A
VCB48A2B
35-5/8" 33-1/2"
Models
Dimensions
