Amana VCA - CCA-FSC & CHA-TSC Uncased A-Coil Specifications

25 Rev. 3
BBA/BBC BLOWER COIL SPECIFICATIONS
C C A - - F S C & C H A - - T S C U n c a s e d A - C o i l S p e c i f i c a t i o n s
MODEL
CCA18FSC
CCA24FSC
CHA18TSC
CCA30FSC
CHA24TSC
CCA36FSC
CHA30TSC
CCA42FSC
CHA36TSC
Evaporator Coil
Face Area (Sq. Ft.) 2.81 2.81 3.75 3.75 4.22
Rows 23233
FPI 1614161413
Drain Connections
Primary 3/4” FPT 3/4” FPT 3/4” FPT 3/4” FPT 3/4” FPT
Auxiliary 3/4” FPT 3/4” FPT 3/4” FPT 3/4” FPT 3/4” FPT
Refrig. Line Connection
Liquid* 3/8" 3/8" 3/8" 3/8" 3/8"
Vapor* 5/8" 5/8" 3/4" 3/4" 7/8"
Approx. Shipping Weight 20 21 24 31 35
* Refer to Outdoor Unit “Specification Sheet” for proper refrigeration line sizes. Installer may need to supply adapter.
C C A - - F S C & C H A - - T S C U n c a s e d A - C o i l S p e c i f i c a t i o n s
MODEL
CCA48FSC
CHA42TSC
CCA54FSC
CHA48TSC
CCA57FSC
CHA54TSC
CCA60FSC
CHA57TSC
CHA60TSC
Evaporator Coil
Face Area (Sq. Ft.) 4.69 5.16 5.16 5.63 5.63
Rows 32334
FPI 1316111110
Drain Connections
Primary 3/4” FPT 3/4” FPT 3/4” FPT 3/4” FPT 3/4” FPT
Auxiliary 3/4” FPT 3/4” FPT 3/4” FPT 3/4” FPT 3/4” FPT
Refrig. Line Connection
Liquid* 3/8" 3/8" 3/8" 3/8" 3/8"
Vapor* 7/8" 7/8" 7/8" 7/8" 7/8"
Approx. Shipping Weight 36 38 45 47 56
* Refer to Outdoor Unit “Specification Sheet” for proper refrigeration line sizes. Installer may need to supply adapter.
CCA_FSC & CHA_TSC
"A" COIL SPECIFICATIONS
