Amana VCA - Page 22

BBA/BBC BLOWER COIL SPECIFICATIONS
22 Rev. 3
CCA_FCC, FDC & CHA_TCC
CASED COIL SPECIFICATIONS
4 3/4
W
H
7
1 5/8
2 3/4
2
W
1
H
2
B (Top) or
C (Bottom)
A
21 1/8
Cabinet A-Coil Coil Cabinet
Supply Air Return Air
Width Model Cases Height Opening Opening
( W ) ( CCA--F*C ) ( CHA--TCC ) CCD-- ( H ) (A x B) (A x C)
CCA18FCC
Small CCA24FCC CHA18TCC 14 1/4
( 16 1/2 ) CCA30FCC CHA24TCC 15 x 18 3/4 15 x 20 3/16
CCA36FCC CHA30TCC
CCA42FCC CHA36TCC CCD16A22 22 1/4
CCA30FDC
Medium CCA36FDC CCD20A22
( 20 1/2 ) CCA42FDC
CCA48FCC CHA42TCC
CCA36FKC
CCA48FDC
Large CCA54FCC CHA48TCC 26 1/4 23 x 18 3/4 23 x 20 3/16
( 24 1/2 ) CCA57FCC CHA54TCC CCD24A26
CCA60FCC CHA57TCC
CHA60TCC
18 1/4
22 1/4
19 x 20 3/1619 x 18 3/4
