Amana VCA - Page 39

39 Rev. 3
AIRFLOW DATA
Static Pressure Drop Across Coil Versus CFM
CCH24F
CHH24T
CCH30F
CHH30T
CCH36F
CHH36T
CCH48F
CHH48T
CCH60F
CHH60T
Rated CFM = 800 Rated CFM = 1000 Rated CFM = 1200 Rated CFM = 1600 Rated CFM = 1800
Wet
Coil
Dry
Coil
Wet
Coil
Dry
Coil
Wet
Coil
Dry
Coil
Wet
Coil
Dry
Coil
Wet
Coil
Dry
Coil
0.050 --- 760
--- --- --- --- --- --- --- ---
0.075 640 1140
--- --- --- --- ---
810
--- ---
0.100 860 ---
---
820
---
960
---
1080
--- 1350
0.125 1070 ---
---
1020 560 1090 840 1350
--- 1530
0.150 --- --- 760 1220 670 1220 1000 1610 1280 1710
0.175 --- --- 890
---
780 1340 1170 1880 1390 1900
0.200 --- --- 1010
---
890 1460 1340
---
1490 2100
0.225
--- ---
1140
---
1000
---
1510
---
1590 ---
0.250
--- ---
1270
---
1110
---
1670
---
1680 ---
0.275
--- --- --- ---
1220
---
1840
---
1760 ---
0.300
--- --- --- ---
1330
--- --- ---
1830 ---
Static
Pressure
Drop
Across
Coil**
