２２
4.Operation (continue)
Be sure to read and understand on the page 3 to 7 “For safety operation” carefully before use
Setting of data
Import
ant
●Setting of each data can be changed during stopping the operation.
●Wh
en operating by external, make sure to activate “(5) External operation setting”( at the Ｐ.２７
) If the
sign
al wires are not connected, conn
ect the wires.
Set the data due to the working condition. In this section shows the setting of the type of oil mist to collect,
the setting of maintenance timer and the data setting of external operation.
Setting conte
nts Function Selection Default
Refer
Page
(1)
n-00
Mode setting
Select “oil” or “soluble” according to the type of the mist. If the
object substance is oil mist and high density and spark
discharge occurs frequently, select 90％ of oiliness. If the
object substance is soluble mist and leak the soluble mist
from exhaust port, select the soluble110％.
000・・・oil 100％/001・・・soluble100％
002・・・oil 90％/003・・・soluble110％
Essential 000
Ｐ.２３
(2)
n -01
High voltage
delay setting
When this setting is enabled, the high voltage operation is
operated for 70％ to 80％ until 30 seconds of starting the
operation the high voltage output and after 30 seconds of the
starting, rated high voltage output is done.
000・・・Non active /001・・・Active(Low output operation until 30
seconds after starting)
Optional 000
Ｐ.２４
(3)
n-02
Fan
Continuous
operation setting
If the spark discharge or short circuit occurs due to the
contamination attached with electrode, all operation is
stopped. If this setting is enabled, only the high voltage output
is stopped and fan operates continuously. It is effective, if
discharging the mist regularly. When stopping the high voltage
operation, mist that is not collected is discharged. Be sure to
check the discharge root before the setting.
000・・・Non active/001・・・Active
Optional 000
Ｐ.２５
(4)
n-03
Maintenance
Timer setting
By this setting, when the operation time is reached by the
setting time, inform the maintenance period of electrode.
Default of timer setting is 2000 hours. Due to the operation
condition, change the setting time.
※ For about 2000 hours of the operation of 8hours / day
20days/month 12month/year
※ The setting time is counted per 1 hour. When reaching 0hour,
maintenance is needed.
※When the alert of maintenance displayed, operation continues.
The setting range…0～9000 Available of setting per 100 hours
Change
according
to your
needs
2000
Ｐ.２６
(5)
n-04
External
operation setting
In addition to operation by control panel; this machine can be
operated by external signal of machine tool or switch. By this
setting, select the type of external operation.
About the signal type：
T
his machine can be operated by continuous signal or the
one-shot signal. If one-shot signal is operated, operates when
closing the contact and stops when opening the contact.
During the one-shot signal, once the contact is closed, the
circuit is changed inside the machine. It need not continuing
the contact closed.
000・・・Manual/001・・・Continuous/002・・・One-shot
Essential
during
external
operation
000
Ｐ.２７
To Next Page
