Commissioning
16
AMADOS BAG0083.2 11.17
5.4 Enter working width
Display of working width
1. Actuate the key.
→ Current value is displayed.
2. Enter the value with the
or keys.
3. Confirm with the
key.
4. Set the position of the spread deflector with the
/
key according to the table below.
Adjustable working widths [m]
Salt
1,5 - 4
Sand, gravel, slag
2 – 5
Fertiliser
1 - 10
Allocation of panel position to working width
Product
1
2
3
4
5
Spread deflector position
Gravel

Sand

Salt

Slag

Fertiliser

90°

5
5
4
5
X
60°

4
4
3
4
45°

3
3
2
3
30°

2
2
1.5
2
Working width [m]
• The smallest adjustable position of the spread deflector is 30°.
• The spread deflector is raised completely (90°) for spreading
fertilizer und is not adjustable via the
/ keys!
