Amazone AMADOS E+S - Deleting Job Data; External Job (ASD)

Commissioning
20
AMADOS BAG0083.2 11.17
5.5.2 Deleting job data
Delete the data stored for a job as follows.
1. Actuate the key (several times if necessary).
→ Select the job to be deleted.
2. Actuate the
and keys simultaneously.
→ Job data are deleted.
3. Actuate the key.
→ work display
5.5.3 External job (ASD)
Using a PDA computer, an external job can be
transferred to the AMADOS
E+S
.
This job is always given the designation AE (Fig.
2).
Fig.
2
The data is transferred via the serial interface.
• For this purpose, set the transfer rate of the
serial interface to 19200 or 57600 baud
(mode 9).
• The Y cable is required for this.
Fig. 3/...
(1) Connection for PDA computer
(2) Connection for signal socket or sensor for
impulses per minute.
(3) Connection to AMADOS
E+S
(4).
The external job is started and ended via the
connected computer.
Emergency termination of the external job on the
AMADOS
E+S
:
• Actuate the
and keys simul-
taneously
Fig.
3
