Cleaning, maintenance and repairs
216 Citan 12001-C/15001-C BAH0094-3 12.2019
12.8 Servicing roller chains and chain wheels
On all roller chains, at the end of the planting season
 Clean (including the chain wheels and chain tensioner)
 Check
 Lubricate with low-viscosity mineral oil (SAE30 or SAE40).
12.9 On-board electrical system maintenance
A well conducting connection must always be established between
the generator and the ground connection of the battery. All parts of
the system such as the cable, connector, etc. must be connected
correctly. The cable insulation must not be damaged.
DANGER
Repair damaged cables immediately!
12.9.1 Battery
The battery (Fig. 309/1) and the fuse (Fig. 309/2)
are located under the flap on the right side of the
implement.
 The battery is maintenance free.
 If the battery has to be charged using a
quick charger, first remove the pole termi-
nals!
Fig. 309
During welding work on the machine.
 Always disconnect the power
supply from the tractor.
 Disconnect the battery cable.
12.9.2 Disconnecting the power supply
 Ensure that the battery is connected cor-
rectly – connect the positive terminal first
and then connect the negative terminal!
When disconnecting the battery, disconnect
the negative terminal first, followed by the
positive terminal.

A
lways place the appropriate cover over the
positive battery terminal. If there is acci-
dental earth contact, there is a risk of ex-
plosion
 Store the batteries in a dry area during the
winter periods (corrosion).
