Hydraulic diagram
Citan 12001-C/15001-C BAH0094-3 12.2019 243
Fig. 335/… Description Notification
10 Tractor hydraulics
20 yellow 2
30 yellow 1
40 blue 1
50 blue 2
60 green 1
70 green 2
80 red T
90 red 1
100 Star wheel lift-out
105 Star wheel locking block
110 Frame load control block
115 Sections pressure gauge
120 Blower fan drive
130 Coulter pressure gauge
140 Sections pressure gauge
150 Lift-out, right
155 Fast lowering control block
160 Lift-out, left
165 Fast lowering control block
170 Star wheel control valve
180 Distributor head folding control valve
190 Distributor control block
200 Folding on the left
205 Hyd. accumulator, folding on the left
210 Folding on the right
215 Hyd. accumulator, folding on the right
220 Distributor head folding, right
230 Distributor head folding, left
240 Coulter pressure, left
250 Coulter pressure, right
300 Harrow pressure Option
310 Harrow pressure, left
320 Harrow pressure, left
330 Harrow pressure, right
340 Harrow pressure, right
600 On-board unit
610 Manual directional valve
620 Blower fan pressure gauge
630 Ventilation filter
640 Return filter
650 Oil tank
660 Pump
700 Radiator in combination with on-board unit
800 Generator drive Option
900 Tractor wheel mark eradicator Option
910 Wheel mark eradicator cylinder
920 Wheel mark eradicator check valve
930 Wheel mark eradicator control valve
All position specifications in direction of travel
