Ambient Weather WS-0802 User Manual

Version 1.0 ©Copyright 2017, Ambient LLC. All Rights Reserved. Page 3
2 Getting Started
Note: The power up sequence must be performed in the order shown in this section (insert
batteries in the remote transmitter(s) first, Display Console second).
The WS-0802 weather station consists of a display console (receiver), and a thermometer (remote
transmitter).
2.1 Parts List
QTY
Item
1
Thermometer transmitter (FT007T)
Dimensions (LxHxW): 4.5” x 2.0” x 0.75”
1
Display Console
Frame Dimensions (LxHxW): 4.77 x 2.95 x 0.6 in
LCD Dimensions (LxW): 3.00 x 1.17”
LCD Segment Height: 0.70 inches
1
User Manual
2.2 Thermometer Sensor Set Up
Note: Do not use rechargeable batteries. We recommend fresh alkaline batteries for temperature
ranges between -4 °F and 140 °F and fresh lithium batteries for temperature ranges between -40 °F
and 140 °F.
1. Remove the battery door on the back of the sensor by removing the set screw, as shown in
Figure 1 .
Figure 1
2. BEFORE inserting the batteries, locate the dip switches on the inside cover of the lid of the
transmitter.
Figure 2 displays all four switches in the OFF position (factory default setting).
