23
SET/OK 4
O
F
DUCT TEMP LOW
122
SET/OK
I
O
F
DUCT TEMP H
GH
SET/OK 85
O
F
HEAT OFF OS TEMP
0
SET/OK
O
F
SENSOR OFFSET
1 Hrs
SET/OK
OVERT I ME
MAX I
MUM
1 Hrs
SET/OK
VENT
MAX I MUM
SET/OK 30 Secs
FAN DELAY
SET/OK 120 Secs
POST PURGE
3
SET/OK
O
F
T SET DEAD BAND
FROM BOTTOM OF LAST PAGE
MOVE TO TOP OF NEXT PAGE
23
4
SET/OK
O
F
T SET BANDWIDTH
Set control temperature set point Dead band.
Range 2 to 8°F
Set duct temperature set point low limit above
room temp set point. Range 0 to 36°F
Set duct temperature set point high limit.
Range 75 to 140°F
Set outside air temperature set point
(if turned on above). Range 50 to 85°F
Set space temperature reading offset.
Range -9 to 9°F
Set overtime maximum allowed.
Range 0 to 10hrs.
Set Radiant / ARC / Herringbone fan delay
time. Range 0 to 240secs
Set Radiant / ARC / Herringbone post purge fan
time. Range 0 to 240secs
Set vent mode maximum allowed.
SET/OK OFF
OS TEMP
Turn ’ON’ for optional External
Air Sensor.
Set control temperature set point Bandwidth.
Range 4 to 18°F
To Next Page
