User's manual
GB
The robot Ambrogio Line 200 is pro-
duced in the BASIC, DELUXE and EVOLU-
TION versions.
BASIC version: basic model which can
mow surfaces up to 1500 m
2
. On re-
quest, it can be equipped with two lead
batteries or a lithium battery.
DELUXE version: model able to mow
surfaces up to 2600 m
2
. On request, it
can be equipped with two lithium batter-
ies, which make it possible to mow sur-
faces up to 3000 m
2
.
EVOLUTION version: model able to mow
surfaces up to 3000 m
2
. It is equipped
with two lithium batteries, telecommand
and sensor to detect the "mown lawn".
All models are equipped with a sensor
which, when it rains, stops the blade and
makes the robot return to its recharging
station.
On request, models can be equipped
with an amplified transmitter, electro-
magnetic interferences filter, electronic
alarm and power supply protection box.
For more details, consult the table show-
ing technical data
Each robot is provided with a recognition
password in order to impede its use
should it be stolen.
When the purchased, the password in-
serted by the manufacturer comprises
four numbers (0000).
To customise the password see "Pro-
gramming mode" (§ "Enter password").
Main parts
– Accumulator batteries (A): they en-
ergize the motors of the blade and of
the wheel control system.
The robot is supplied with lead batter-
ies or with one or two lithium batter-
ies, which assure a longer working
session.
– Recharging station (B): used to
charge or keep the batteries charged
(A).
– Electronic card (C): it checks the au-
tomatic functions of the robot.
– Control keyboard (D): it is used to set
and visualise the functioning modes of
the robot.
– Cutting blade (E): it trims the lawn.
– Electric motor (F): it starts the cut-
ting blade (E).
– Electric motor (G): one actions the
right wheel transmission group while
the other actions the left wheel.
– Transmitter (H): it transmits the sig-
nal to the perimeter wire.
– Power supply unit (L): it energizes, at
low tension, the battery power.
Important
The power supply unit (L) varies ac-
cording to the type of batteries in-
stalled (lead or lithium batteries).
– Impacts sensor (M): detects robot
impact against an obstacle and ena-
bles a change of trajectory in a ran-
dom manner.
– Remote control (N): it is used to
check the robot functions in a remote
position.
– Rain sensor (P): detects rain and en-
ables the return of the robot to its
charging station (P).
– Sensor (Q): detects the perimeter
wire and enables a change of robot
trajectory in a random manner.
