- 62 -
C141501700.fm
User's manual
GB
1-Stop the robot in safety condi-
tions (see "Robot safety stop").
2-Remove the cover (A).
3-Extract the battery (B) and re-
place it with one of equal volt-
age
Important
When reassembling the new bat-
tery respect the relative polari-
ties (+ e -).
Do not damage the circuits in-
side the telecommand.
4-Install the cover (A).
Start the robot and manoeuvre it
with the telecommand to check bat-
tery efficiency.
Danger - Attention
Do not dispose of pollutant materials in
the environment. Dispose of all such
materials in compliance with applica-
ble legislation.
TELECOMMAND BATTERIES REPLACEMENT THE BLADE
ROBOT DISPOSAL
IDM - 41501711000.tif
cover (A)
battery (B)
