1:45
Battery
The time stamp indicates the time left on the battery while using a
visualization device.
Current Procedure View videos and snapshots recorded in the current procedure.
Image Adjustments
Adjust colour, contrast, sharpness, brightness, and image orientation
(180 degrees rotation).
When one of the other tabs (Archive, Login or Settings) in the tool bar is activated a first level menu opens extending over
the black area left of the live image area. If no action is taken within 5 seconds, the first level menu will close again. If user
selects any of the sub-menus, a new menu will open that covers the live image.
5.1.1. Adjusting live image appearance
In the Image Adjustment menu, you can change the Colour, Contrast and Sharpness in the live image as well as the
Brightness (backlight) of the LCD screen. An Image Rotation function is also available and explained in section 5.1.2.
To change the image parameters:
• Press the Image Adjustment
icon to open the menu.
• Adjust the image settings. Either press the icon at each end of the slider bar or drag the slider left/right on the bar.
23
EN
