AMD FirePro W7000 - Connecting Displays

Figure 3–2 AMD FirePro™ W7000 Stereoscopic Connection
1 Stereoscopic Connection
The following figure shows where the cable from the sterescopic bracket connects to
your AMD FirePro™ W7000 graphics card.
Figure 3–3 Sterescopic Cable Connection
3.2 Connecting Displays
The following table lists the different ways you can connect displays to your card:
8 Display Configuration
AMD FirePro™ W7000 Graphics Accelerator © 2012 Advanced Micro Devices Inc.
