Figure 6–4 Two PCs with Four GPUs Each Framelocked
This diagram shows an advanced framelock and genlock setup using four PCs with
four GPUs each; each computer is connected to an AMD FirePro™ W7000
synchronization module synchronized with an external signal generator.
