PC Interface | A-3
Baud Rate Select the baud rate at which data will be transferred.
RS-232 Port Click if the analyzer is connected to an RS-232 port.
RS-485 Port Click if the analyzer is connected to an RS-485 port.
Address Type the network address to which the analyzer is con-
nected.
Saving Your Settings
To save PC Communications settings, click OK.
To abort changes you have made, click Cancel.
Device
Refer to Figure A-1.
Name Type in a name for the analyzer.
Description Type in a description for the analyzer.
Save Configuration button
Save the analyzer’s internal parameters to a file. The Save As
dialog box opens so that you can name and save the file.
Restore Configuration button
Restore the analyzer’s internal parameters from a file. The
Open dialog box appears so that you can select and open the
file.
The Restore Configuration button can also be used to restore the analyzer
communications parameters.
Live Data
Checked The system connects to and uses live data from the analyzer.
Not checked The system uses demonstration data.
Status
Indicates if the analyzer is on-line, off-line, or in demo mode.
NOTE
