Refrigerating/Heating Baths
Standard Digital
Temperature Controller
Reservoir Cover
Reservoir Drain Valve and Port
(behind access panel)
Side access on TC-550SD)
Drain Valve and Port
(right side on TC-550SD)
Washable Air Filter
(behind access panel)
IEC Power Connection to
Refrigeration Power Module
IEC Power Connection
to Mains
Refrigeration Power Module
IEC Power Connection
to Controller
Power Switch / Circuit Breaker
Refrigeration Control
Connection
Cooling System Status Display
Refrigeration Control
Connection
Power
Cooling
Fan
Cooling Fault
Thermometer Port
