Controls and Components
Standard Digital Controller
3.75” Color
LCD Display
Touch Scroll Bar
Set Key
Menu Key
Power Key
Home Key
Swivel 180
Latch Release
IEC Power Cord
Power Switch /
Circuit Breaker
(located on Refrigeration
Power Module on
Refrigerating/Heating
Circulators)
Safety Set
Thermostat
Refrigeration Control
Connection (functional on
Refrigerating/Heating
Circulators only)
Fluid Inlet Connection
RS232 Serial Port
Fluid Outlet Connection
Inert Gas Port
IEC Electrical Connection
Bypass Tubing
Safety Set Reset
Access
