Page #5 background imageLoading...
Page #5 background image
110-512 BEL/EN
4
Performance Specifications
Model dependent; see table below
±0.04C (±0.08°F)
2-speed pressure
60Hz models
50Hz models
3.5 psi (0.24 bar)
2.9 psi (0.20 bar)
2.9 gpm (11.0 lpm)
2.7 gpm (10.2 lpm)
1100 watts
2200 watts
Model Type
Reservoir
Capacity
Internal
Working Area
(L x W x D)
Overall
Dimensions
(L x W x H)
Gross
Weight
Temperature
Range
TC-150SD
Heated Circulator
6 liters
4.5 x 4.0 x 6.0 in.
14.4 x 10.2 x 15.2 cm
13.4 x 8.1 x 14.9 in.
34.0 x 20.6 x 37.8 cm
26 lbs.
11.8 kg
Ambient +10° to 150°C
Ambient +20° to 302°F*
TC-250SD
Heated Circulator
10 liters
5.0 x 11.0 x 6.0 in.
12.7 x 27.9 x 15.2 cm
13.9 x 13.5 x 14.9 in.
35.3 x 34.3 x 37.8 cm
45 lbs.
20.4 kg
Ambient +10° to 150°C
Ambient +20° to 302°F*
TC-550SD
Refrigerating/
Heating Circulator
7 liters
6.18 x 5.59 x 5.0 in.
15.7 x 14.2 x 12.7 cm
23.2 x 16.2 x 16.2 in.
58.9 x 41.1 x 41.1 cm
90 lbs.
40.8 kg
-20° to 170°C
-4° to 338°F
TC-650SD
Refrigerating/
Heating Circulator
7 liters
6.18 x 5.59 x 5.1 in.
15.7 x 14.2 x 12.9 cm
21.3 x 8.7 x 24.3 in.
54.1 x 22.1 x 61.7 cm
90 lbs.
40.8 kg
-20° to 170°C
-4° to 338°F
* Upper temperature limit based on reservoir construction. Temperature controller capable of higher temperatures.
Model Type
Electrical Requirements **
120V Units
240V Units
TC-150SD Heated Circulator
120V, 60Hz, 10A
240V, 50Hz, 10A
TC-250SD Heated Circulator
120V, 60Hz, 10A
240V, 50Hz, 10A
TC-550SD Refrigerating/Heating Circulator
120V, 60Hz, 12A
240V, 50Hz, 12A
TC-650SD Refrigerating/Heating Circulator
120V, 60Hz, 12A
240V, 50Hz, 12A
** Voltage Utilization Range: +/- 10% from Listed Nominal Voltage
Environmental Conditions Indoor use only
Maximum Altitude: 2000 meter
Operating Ambient: 5° to 35°C (41° to 95°F)
Relative Humidity: 80%, non-condensing
Installation Category: II
Pollution Degree: 2
Ingress Protection: IP 31
Climate Class: SN
Software Class: B
Output Waveform: Sinusoidal
Specifications subject to change without notice.
