38 26-03-2004 123200 03
4.2 List of spare parts – CTC-140 A/-RS, MTC-
140 A
Pos. Spare parts Number
(Compare exploded view, next page)
1 Keyboard (CTC) 105247
1 Keyboard (MTC) 105436
3 16 circuit ribbon cable 105102
4 10 circuit ribbon cable 105112
5 Reference sensor wire w. 4-poled connector 105140
7 Grid plate 105000
11 Cable for Peltier elements 105103
13 Power PCB 105065
15 Well, cpl. incl. sensor 105258
16 Transformer 105137
17 Fan 105264
19A I/O plate (MTC) 105434
19A I/O plate (CTC) 123662
19B I/O plate with RS232 connection (CTC) 105357
21 Wire for I/O plate, 145 mm. 105149
- Reference sensor 105287
- Controller PCB w. R1 + R6 105245
- Washer for display 104559
- Fuse 115V, 2AT 105014
- Fuse 230V, 1AT 105007
- Fuse 4 A (T), 5x20mm IEC 105334
- Screw for fan, M5x25mm 60V103
- Rubber foot for fan and PCB, black 60N131
- Rubber foot for bottom part, black 60G032
- Power entry module, PSOSXSS3A 60E013
- Screw, UNC-4-40 (for RS232 - CTC) 122513
- Screw set, complete 123382
