44 26-03-2004 123200 03
4.5 List of spare parts – CTC-320 B/-RS
Pos. Spare parts Number
(Compare exploded view, next page)
1 Keyboard 105247
3 16 circuit ribbon cable 105102
4 10 circuit ribbon cable 105112
5 Reference sensor 105290
7 Grid plate 105000
11 Cable for power inlet 105101
13 Power PCB 105249
16 Well, cpl. incl. sensor 105259
17 Fan 105257
19A I/O plate 123664
19B I/O plate with RS232 connection 105359
21 Wire for I/O plate, 145 mm. 105149
22 Wire for well, 145 mm. 105104
- Controller PCB w. R1 + R6 105245
- Washer for display 104559
- Rubber foot for bottom part, black 60G032
- Fuse 115V, 10AF 60B302
- Fuse 230V, 5AF 60B301
- Fuse 63 mA (T), 5x20mm IEC 105333
- Fuse 100 mA (T), 5x20mm IEC 123850
- Fuse 160 mA (T), 5x20mm IEC 124494
- Cover for fuseholder 105332
- Power entry module, PSOSXSSXA 60D542
- Screw, UNC-4-40 (for RS232) 122513
- Screw set, complete 123382
