48 26-03-2004 123200 03
4.7 List of spare parts – CTC-1200 A-RS
Pos. Spare parts Number
(Compare exploded view, next page)
1 Keyboard 105247
3 16 circuit ribbon cable 105102
4 10 circuit ribbon cable 105112
7 Grid plate 124338
13 Power PCB 124264
16 Transformer 124335
17 Fan 105257
19 I/O plate with RS232 connection 124563
20 Well, cpl. incl. sensor 124570
21 Wire for I/O plate, 145 mm. 124354
21 Wire for well, 145 mm. 124354
- Controller PCB w. R1 + R6 124582
- Washer for display 104559
- Rubber foot for bottom part, black 60G032
- Fuse 115V, 6.3AT 60B313
- Fuse 230V, 3.15AT 60B312
- Fuse 800 mA (T) 124428
- Cover for fuseholder 105332
- Power entry module, PSOSXSSXA 60D542
- Screw, UNC-4-40 (for RS232) 122513
- Screw set, complete 123382
