8 26-03-2004 123200 03
CTC-1200 A 1. 50°C / 122°F
2. 300°C / 572°F
3. 600°C / 1112°F
4. 900°C / 1652°F
5. 1200°C / 2192°F
Prepare to adjust/calibrate the instrument by doing the following (see
Fig. 1):
Caution…
• The well and the insertion tube must be clean before
use.
• The insertion tube must never be forced into the well.
The well could be damaged as a result, and the
insertion tube may get stuck.
• Do not touch the tip of the sensor when it is removed
from the insertion tube/well – it may be very hot.
Insulate the part of the sensor which is above the heating
well (use insulation tube part no. 65-F100 to 65-F107 and
insulation 30x30 mm part no. 105173).
Protect the sensor head from heat radiation from the well
by use of thermal protection shield (part no. 104216) or
similar.
B
