Installation Manual - Rev D California Instruments
MX Series 11
The input power cables and protective circuit breaker used must be large enough to handle the
input current and input voltage of the power source and must conform to local electrical codes.
Consult a qualified electrician prior to installation. Table 2-1 shows the size of the cables that may
be used per MX45 cabinet. Note that wires must be sized to accommodate the worst-case
maximum current that may occur under low line conditions. Local electrical codes may also
require different wire types and sizes. These ratings should also be used when selecting a circuit
breaker or equivalent disconnect device.
Cable lengths must not exceed twenty-five (25) feet. For lengths greater than 25 feet, calculate
the voltage drop from the following formula:
2 X DISTANCE X CABLE RESISTANCE PER FT. X CURRENT = VOLT DROP
Table 2-1: Suggested Input Wiring Sizes for each MX45 Cabinet
Nominal Line
Voltage
Load Current
@ low line
Circular Mils
(Kcmils)
Metric (mm2)
480 V
75 Arms
26.24
13.3
400 V
90 Arms
41.74
21.1
230 V
157 Arms
66.36
33.6
208 V
175 Arms
83.69
42.4
CAUTION: Capacitors in the power source may hold a hazardous electrical charge
even if the power source has been disconnected from the mains supply. Allow
capacitors to discharge to a safe voltage before touching exposed pins of mains
supply connectors.
Power modules need at least 15 Minutes to discharge to safe levels before they can be
removed.
2.5 AC On/Off Circuit Breaker on MX45 front panel.
It is important to understand the purpose and operation of the On/Off circuit breaker of the MX45
located on the lower left side of the front panel. This is a 2A rated breaker that is used to engage
and protect the LV Power supply of the MX45 chassis only. The LV Power supply provides DC
bias power to the entire MX45 system. The AC input power is routed through a set of three AC
line fuses (F1, F2 and F3) located in the lower left bottom corner of the MX45. (See Figure 2-2 for
fuse locations). These fuses protect the three MX45 amplifier and the AC input transformer from
excessive input currents. The AC input power is connected to the input transformer through a
large three pole contacter. Removing AC power to the LV Power Supply by opening the front
panel circuit breaker (moving the lever to the down (OFF) position) will cause this contactor to
loose its coil voltage and will result in it opening and disconnecting the input transformer and
amplifier from AC mains input.
Note: If any MX45 system failure has occurred on any part of the MX45 system, AC input
power must be removed immediately and not restored until the system has been
inspected by a qualifier service technician.
Always turn off the On/Off Circuit breaker before re-applying AC input power.
