3.6.2. Final position
Please check the maximum floor loading of the position where the NetWave is places and compare with the
weight in kg/m2.
NetWave :
Weight
Area
device
Floor loading
approx.
20.x
740 kg
0.59 m
2
1260 kg/m
2
30.x
740 kg
0.59 m
2
1260 kg/m
2
60.x, 67.x
1180 kg
0.96 m
2
1230 kg/m
2
90.x
1700 kg
1.45 m
2
1175 kg/m
2
108.x
1700 kg
1.45 m
2
1175 kg/m
2
20.x with recovery
810 kg
0.76 m
2
1070 kg/m
2
30.x with recovery
810 kg
0.76 m
2
1070 kg/m
2
60.x, 67.x with recovery
1380 kg
1.29 m
2
1070 kg/m
2
90.x with recovery
2000 kg
1.93 m
2
1070 kg/m2
108.x with recovery
2000 kg
1.93 m
2
1070 kg/m2
3.6.3. Dimensions
NetWave 20.x / 30.x with recovery
Height (rolls+crane support) 1560 (1784) 1560 (1784)
Width 930 1210
Depth 755 755
NetWave 60.x, 67.x with recovery
Height (rolls+crane support) 1800 (2080) 1800 (2080)
Width 1205 1615
Depth 970 970
NetWave 90.x, 108.x with recovery
Height (crane support) 1800 (1880) 1800 (1880)
Width 1810 2410
Depth 970 970
Note: For detailed dimensional data please refer to chapter “Technical data”.
