AMETEK CTs NetWave

3.6.9. Control cable wiring

Note

1. Signal control cable

Make sure that the bridges for L1, L2, L3

SIGNAL OUT to SOURCE IN

are connected.

2. Computer – NetWave control cable

There are two solutions to connect the computer to the

NetWave.

- Ethernet connection

- IEEE connection

Connection to

Standalone equipment

- Ethernet

- USB via USB-Ethernet adapter (direct

cable)

Rack with other equipment

– IEEE 488 / GPIB

Note

Ethernet cables

Check the correct cable wiring when using ethernet cables.

- Direct => normal straight cable

- USB-Ethernet Adapter => direct cable
