3.2.2. Front Panel
The PARSTAT 4000 front panel is shown in Figure 5.
FIGURE 5 PARSTAT 4000 front panel
3.2.2.1. CELL CABLE Connector The cell cable connector provides a
means of connecting a cell cable to the instrument. The cell cable is
described in more detail below.
3.2.2.1. Front Panel Display
3.3. Connecting to the PC and Cell
This section gives instructions on connecting the PARSTAT 4000 to the host PC and to
electrochemical cell and other equipment.
WARNING: For operator and equipment safety, power to all instruments should
be off when connecting or disconnecting cables.
3.3.1. Connecting to the PC
The PARSTAT 4000 is shipped with a standard USB cable. Connect it between the rear-
panel USB connector and a USB port on the PC. As noted above, it is not necessary to
shut down and restart Windows or VersaStudio.
3.3.1.1. Installing the USB Driver
Installing the USB Driver
