Technical Specifications for Power Turntable
PART NUMBER
TRK-TRN-TBL-M-4-PT
The power turntable is a motorized turntable that works with the GoLift to rotate a patient between tracks. The power
turntable uses GoLift batteries to power a motor located in the side of the turntable in order to rotate the track.
• Maximum capacity: 1000 lbs
• Turning Angle: 90° with maximum turn limit detection
• Adjustable tension wheel
• Up to four (4) directions. Minimum three (3) directions
• Compatible with the regular Amico track with built in track brackets
• Operates at 24V DC (Power supplied from the GoLift)
TROLLEYS
• GO-LIFT-QR-TRLY-PTT-ASSY
• GO-LIFT-QR-TRLY-PTT-100-ASSY
• Must be used with a power turntable compatible trolley
• No maintenance required
• Magnetic mounted access panel for servicing if required
• 10 year service life
HOW TO OPERATE
All functions are operated through the lift hand control. If the track option is not available,
the lift will still register the button, but nothing will happen.
The Amico 4 Port Turntable is suitable for installations
where junctions are required in a track or when a track turn
is required that a standard curved sections cannot achieve.
The Turntable provides ultimate flexibility in lift and
transfer situations that demand a wide range of locations,
or require specialized options.
The four (4) exits of the Turntable allow multiple
configuration options for the system designer and gives
the user more options for the installation. An adaptation
that is being planned can be designed around the angles
of the turntable. For example, a turntable in a bathroom
could be positioned so as to allow transfer between chair,
bath, wheelchair, shower area and or changing stretcher.
