www.amico.com 15
1. Use a 3/16" Allen key to secure the endstop to the track.
Connecting the Carry Bar to the Lift Strap
1. Hold the Carry Bar and press the button using the
thumb as shown.
2. Insert the strap hook into the slot on top of the carry bar and
release the button.
3. Check that the button has returned to its locked position by
checking that it is flush with the cover
of the Carry Bar and that the strap attachment
can rotate freely.
Connecting the Hand Control to the Carry Bar or Wall Plate
Magnetic Hand control connect for quick attachment to Carry Bar or wall plate.
WARNING: Do not place the hand control within 6" of a pacemaker. Patients with
pacemakers must follow the instructions provided by their doctors.
Installing the Endstop on the Amico Track
Amico Track Endstop
