Technical Specifications for Power Traverse
The power traverse module is a motorized trolley that works with the GoLift in order to drive a patient within an
Amico track system with the press of a button. The power traverse is compatible with all models of the GoLifts. The
power traverse trolley has a cable that plugs into the GoLift in order to draw power from the GoLift battery. The GoLift
batteries power the motors within the trolley in order to move the assembly laterally within the track. When the power
traverse is parked in a charging area on the track and is not in use, it transfers charge from the track to the lift in order
to charge the batteries. The power traverse also transfers power from the lift batteries back into the track through the
horizontal contacts in order to power the powered turn table and powered gantry options.
FOUR MODELS
GO-LIFT-QR-TRLY-PT-ASSY: 700 lbs
GO-LIFT-QR-TRLY-PT-1000-ASSY: 1000 lbs
GO-LIFT-QR-TRLY-PTT-ASSY: 700 lbs (power turn table compatible, manual traverse)
GO-LIFT-QR-TRLY-PTT-100-ASSY: 1000 lbs (power turn table compatible, manual traverse)
• Maximum traverse speed: 3.64"/s
• Soft start & soft stop: Accelerates and decelerates to minimize patient swing
• Designed for continuous operation
• Transfer power from the lift up to the power turn table & power gantries if available
• Annual maintenance: reapply grease to the motor gears
• Weight: 3 lbs
• Compatible with any Amico track
5.217
6.024
1.050
2.851
2.022
3.848
5.192
4.172
4.172"
7.18 4“
5.217
6.024
1.050
2.851
2.022
3.848
5.192
1.050“
5.217“
6.024“
2.022“
3.848“
5.192“
2.851“
DIMENSIONS OF THE POWER TRAVERSE
